Solution Overview & Testing Methodology
A photovoltaic or PV inverter converts the direct current (DC) output of a solar cell or array into an alternating current (AC) that can be fed directly into the electrical grid (Grid Tie), used by a local electrical grid (Off-Grid), or both (Hybrid Inverters). The PV Inverter is a key component in a photovoltaic system, allowing the use of household and commercial AC powered devices.
Our test instrumentation provides means to further the development, reliability, and validation of grid-tied, off-grid, and hybrid solar PV inverters that will eventually be used in commercial and household applications for years to come. We do this by integrating features into our testers that, for example, allow performance testing of inverter behavior during voltage and frequency fluctuations found on the grid. And we can do this either by standalone instrumentation or integrated into an automated test system (ATE).
System Test Setup & Architecture Diagram
Core Testing Capabilities & Features
Core Instruments for New Energy & EV Test Solution
AC Power Supply Standard FaithTech Programmable AC power supply FTPF Series
FTPF series programmable AC power supply, using ARM+FPGA digital control, instantaneous waveform control and high frequency pulse width modulation (SPWM) technology, response speed up to 1mS, high output accuracy, low waveform distortion; With three-phase voltage independent adjustable, can edit har
Electronic Load Standard FT68200A/AL/E series high-power DC electronic load (6kW~60kW)
High-speed, programmable dynamic current loading (CCD) for rapid response Supports continuous, pulse, and toggle modes with up to 50kHz dynamic change Offers complex testing modes: CV+CC, CP+CC, and CR+CC Programmable sequence function with up to 100 steps per sequence Unique 30kHz dynamic frequency
Bidirectional DC Power Supply Standard FTB9000 series Bidirectional programmable DC power supply(5kw ~ ±180kW)
Regenerative Load Function : Reduces electricity costs and heat generation by feeding back energy to the factory intranet with 95% conversion efficiency Wide Operating Region : Combines power supply and electronic load with energy recovery capability for seamless switching between sourcing and sinki
DC Power Supply Standard FTP9000 series high-power programmable DC Laboratory power supply (5kW~180kW)
Active Power Factor Correction (PFC) for efficiency Wide AC input range: 340VAC to 460VAC Power factor: 0.99, Efficiency: >93% High power density: 15kW/3U Accurate output, fast response, low ripple noise Wide operating region for varied voltage/current Programmable sequence function for simulations
Need a Custom Test Bench or System Integration?
Our experienced power test engineers can design a tailored hardware and software test setup for your project.
